Wharf Fender Flexible Fit High Performance Long Service Life Compact Design
Description
The V-type Dock Rubber Fender offers unmatched impact protection for ships and dock structures. Made from durable synthetic rubber, it withstands extreme marine environments while providing flexible compression and energy absorption. Its V-shaped design minimizes contact pressure, reducing potential damage to vessels and berths.
Case Study
At the Abu Dhabi Industrial Port, V-type fenders were installed along a bulk carrier terminal. Operators reported a notable reduction in pier maintenance costs and improved vessel docking safety over two years, even under frequent berthing of large ore carriers. The fender’s resilience and low maintenance made it a reliable choice for high-intensity industrial operations.
Specifications
| Place of Origin | China |
| Product Name | Dock Rubber Fender |
| Type | D Shape Type |
| Processing Service | Compression Moulded |
| Color | Black (More Colors Optional) |
| Material | Smooth NR |
| Performance | Excellent chemical and Physical Property |
| Logo | Customer's Request |
| Application | Port, Dock, Boat |
| Type | Specifications | ||||||||
| H | B | L | Holes | Q | C | h | D | d | |
| D150x150x1000 | 150 | 150 | 1000 | 3 | 350 | 150 | 25 | 40 | 24 |
| D200x200x1000 | 200 | 200 | 1000 | 3 | 353 | 150 | 35 | 55 | 30 |
| D200x200x3000 | 200 | 200 | 3000 | 8 | 400 | 100 | 35 | 55 | 30 |
| D250x250x1000 | 250 | 250 | 1000 | 3 | 350 | 150 | 35 | 60 | 30 |
| D250x250x3000 | 250 | 250 | 3000 | 8 | 400 | 100 | 35 | 60 | 30 |
| D300x300x1000 | 300 | 300 | 1000 | 3 | 350 | 150 | 40 | 65 | 32 |
| D300x300x3000 | 300 | 300 | 3000 | 8 | 400 | 100 | 40 | 65 | 32 |
| D300x360x1000 | 300 | 360 | 1000 | 3 | 350 | 150 | 40 | 65 | 32 |
| D300x360x3000 | 300 | 360 | 3000 | 8 | 400 | 100 | 40 | 65 | 40 |
| D400x400x1000 | 400 | 400 | 1000 | 3 | 400 | 150 | 55 | 80 | 32 |
| D400x400x3000 | 400 | 400 | 3000 | 8 | 400 | 100 | 55 | 80 | 40 |
| D500x500x1000 | 500 | 500 | 1000 | 3 | 350 | 150 | 90 | 97 | 45 |
| D500x500x3000 | 500 | 500 | 3000 | 8 | 400 | 100 | 90 | 97 | 45 |
| TECHNICAL DATA | ||
| PROPERTIES | TEST STANDARD | VALUES |
| Compound | - | NR / SBR |
| Density (Specific Gravity) | DIN 53505 | 1200 kg/m3 |
| Tensile Strength | DIN 53504 | ≥16 MPa |
| Elongation at Break | DIN 53504 | ≥350% |
| Tear Resistance (23°C) | DIN 53507 | ≥80 N/cm |
| Abrasion Resistance | DIN 53516 | ≤100mm3 |
| Compression Set (24hrs @ 70°C) | DIN 53517 | ≤40% |
| Ozone Resistance (ppm 20% 72hrs @ 40°C) | ISO 143/1 | No Cracking Visible By Eye |
| Change In Hardness | DIN 53504 | ≤5° |
| Change In Tensile Strength | DIN 53504 | ≥80% |
| Change In Elongation at Break | DIN 53504 | ≥80% |
| Minimum Temperature | - | -30°C |
| Maximum Temperature | - | +70°C |
Features
High Energy Absorption
The V-shaped geometry ensures efficient distribution of impact energy, reducing peak force on both vessel and dock.
Weather and Chemical Resistance
Resistant to saltwater, UV rays, and industrial chemicals, ensuring long-term durability in challenging port environments.
Flexible and Modular Installation
Can be installed on both vertical and horizontal surfaces; individual sections are easily replaceable, minimizing operational downtime.
Long Lifespan and Cost Efficiency
Durable design reduces replacement frequency and operational costs while meeting environmental compliance standards.
Applications
Bulk Carrier Terminals
Protects docks from heavy impacts caused by fully loaded carriers.
Industrial Ports
Withstands chemical exposure and heavy cargo operations.
Passenger Ferry Docks
Reduces impact stress during frequent docking of ferries.
Why Choose Hongruntong Marine?
Strong RD Capabilities
Product development incorporates advanced simulations and real-world testing for optimal energy absorption.
Precision Manufacturing
ISO-certified processes ensure high-quality production for every fender batch.
International Project Experience
Proven installations in Abu Dhabi, Singapore, and Rotterdam validate performance across diverse conditions.
Full Technical Support
Includes installation guidance, maintenance training, and fast after-sales response.
FAQ
1. Can V type fenders be retrofitted on existing docks?
Yes, the modular design allows flexible retrofit installations.
2. What is the typical service life?
8–15 years depending on environmental conditions and vessel traffic.
3. Are they safe for all vessel types?
Yes, suitable for tankers, bulk carriers, container ships, and passenger vessels.
4. Is professional installation required?
While optional, we provide on-site support to ensure optimal installation.
